Common Problems and Solutions in Shotcrete Applications
Common Problems and Solutions in Shotcrete Applications
Shotcrete operations are demanding processes where high-pressure air and abrasive materials meet. Disruptions on-site lead not only to time loss but also to material waste and safety risks. Here are the 4 main problems operators face and their professional solutions:
Problem: Incorrect nozzle angle, excessive air pressure, or a mix that is too dry.
Solution: The nozzle should always be held perpendicular (90 degrees) to the surface at a distance of 1-1.5 meters. The water/cement ratio should be optimized, and the accelerator dosage increased if necessary.
Problem: Oversized aggregate, excessive moisture in the material, or air leaks due to rotor plate wear.
Solution: Aggregate size must match the machine and hose diameter. Rotor sealing plates should be checked regularly and replaced immediately if worn to prevent pressure loss.
Problem: Insufficient water mixing at the nozzle in dry systems or use of low-quality additives.
Solution: Check if the holes in the water ring are clogged. To minimize dust, switch to a wet system pump or use special dust-suppressant additives in dry systems.
Problem: Applying too thick a layer at once, insufficient accelerator, or a dirty surface.
Solution: Clean the surface with compressed air or water before application. Apply concrete in thin layers from the bottom up. Re-calibrate the accelerator dosage based on ambient temperature.
